Product | Gigabit Standard POE Switch 8GE + 2GE+ 1SFP |
Model Number | AP-3038GE |
Product Feature | AI watchdog; restart automatically when crashed |
Power Port | 1- 8 ports, support network power |
Power Transmission Wire Core | 1/2+、3/6- |
Power Input | 100-240VAC 50-60Hz |
Power | 120W; max 30W per port |
Power Transmission Distance | ≤ 150 meters |
VLAN Segregate | Support |
Network Standard | IEEE 802.3AF/AT, IEEE802.3, IEEE802.3U, 802.3X |
Transmission Rate | 10/100Mbps |
Network Medium | Category 5 and above twisted-pair |
Network Signal Distance | ≤ 100 meters |
Switch Capacity | 22 Gbps |
Forwarding Mode | Store-and-forward |
Forwarding Speed | 100BASE-T:14880PPS/PORT |
MAC Address | 2K |
Port Function | Power supply priority, fast transmission, MAC automatic learning and aging, IEEE802.3X full-duplex and backpressure half-duplex |
Indicator Light | Each port has 1 Link/ACT 100Mbps and 1 power light; whole machine power indicator; VLAN indicator |
Working Environment | Working temperature : -20℃ to 60℃ |
Working humidity: 90%, incondensability | |
Storage temperature: -30℃ to 70℃ | |
Storage humidity: 95%, incondensability | |
Weight | 1.5 KG |
Size | 200*142*43mm |
